  PROFESSION  PRECISION
QUALITY

RESEARCH &
DEVELOPMENT

RESEARCH

Our chief engineer has been a leading activist in the field of hydrostatic technology for nearly two decades. We have extensive experience in research and development and have published several papers in the domain.

DEVELOPMENT

We developed sophisticated, integrated restrictors that would create the hydraulic oil film while the hydrostatic bearings are in a stationary condition. Such media has excellent damping capacity to absorb and resist the vibrations because its thickness maintains practically constant irrespective of the load and speed. Hence, it will equalize the pressure coming from different directions throughout the operation. And the accuracy can be easily achieved less than 1μm even in a stationary condition. Most of all, it won’t be restrained by the forms and sizes.

DESIGN

Weibo is a self-designed perfectionist. Through innovative, breakthrough design, we strive to provide cutting edge, reliable, and quality hydrostatic bearings that adapt to the needs of different industrial sectors. We’d take into account variable requests, including technical specifications, applications, and additional options, to present design solutions that exceed one’s expectations and add values to customers’ machine tools. Thus, 99% of our products are tailor-made.

TEST

We aim to deliver high-quality products that surpass stringent standards in every aspect. All the hydrostatic bearings will be thoroughly inspected. We will carry out a complete check of the geometry accuracy before the delivery, including rotation speed, runout, stiffness, and surface temperature.

QUALITY ASSURANCE

Weibo guards the quality of our product with a strict policy, ensuring that products and processes are of the highest quality, superior design, and optimum output. Meaning you can trust our hydrostatic bearings to perform just as well as you do.

HYDROSTATIC BEARINGS

SPINDLE

Housing Dia.:ø45~360 mm

Length:200~1,500 mm

Speed:0 ~ 24,000 r.p.m.

Precision:< 0.5 μm

Static Stiffness:> 10~1,20 kgf/μm

Surface Temperature:5~10 ℃

LINAER GUIDEWAY

Table Size:390 x 440mm ~3,500 x 5,000 mm

Height:250~1,000 mm

Length:800~20,000 mm

Static Stiffness:> 400 ~6,000 kgf/μm

Plan Precision:< 0.0005~ 0.01 mm

Loading Capacity: > 2,000~300,000 kg

Moving SpeedDepend on the transmission system.

Surface Temperature:0~5 ℃

ROTARY TABLE

Rotary Table Dia.:ø200-3,000 mm

Height:187.5~ 800 mm

Axial Precision:< 0.0005~0.005 mm

Radial Precision:< 0.0005~0.003 mm

Speed:0 ~ 6,000 r.p.m.

Static Stiffness:> 20 ~6,000 kgf/μm

Loading Capacity:>500~300,000 kg

Surface Temperature:1~5 ℃

Standard /Optional Accessories
